50mm Waterproof Laminated Padlock – Sealed Keyway, Ø10mm Shackle, Gate & Shed Lock

The 50mm Waterproof Laminated Padlock is the largest of the N-series and the first one in that range with a shackle worth calling heavy. At Ø10mm it is more than double the section of the 30mm, and with 22mm of clearance it takes a proper gate hasp rather than just a cabinet latch.

The body is laminated steel — layer after layer of plate rather than a single casting, so there is nothing to crack under a hammer — sealed inside an over-moulded thermoplastic case. The case is moulded onto the lock rather than slipped over it, so there is no edge to lift, peel or prise off. Behind it a rubber waterproof ring closes off the keyway with a solid brass all-copper lock core, so the mechanism stays dry. An unsealed padlock on an exposed gate is usually stiff within a season and seized within two.

• 43 x 59mm laminated steel body — layered construction resists hammering
• Over-moulded thermoplastic case — bonded to the body, no edge to lift or peel
• Rubber waterproof ring seals the keyway against rain and dust
• Solid brass 4-pin cylinder — all-copper lock core
• A3 steel shackle, Ø10mm with 22mm clearance
• 3 keys supplied
• Suits gates, sheds, enclosures, site cabinets and storage

Security features

Specifications

• Body material: Laminated steel with over-moulded thermoplastic waterproof case
• Cylinder: Solid brass, 4-pin — all-copper lock core
• Shackle: A3 steel
• Locking system: Bolt locking — steel spring, steel pins
• Weather sealing: Rubber waterproof ring
• Keys supplied: 3 keys
• Body size: 43 mm wide x 59 mm high x 26 mm deep
• Shackle: 10 mm diameter, 22 mm clearance
• Weight: approx. 340 g
• Packaging: Double blister
• Country of origin: China
