50mm Wave Shell Weatherproof Padlock – Sculpted Case, Ø8mm Shackle, Front Gate & Shutter Lock

The 50mm Weatherproof Wave Padlock is the mid-size in the wave-shell range and the pick of it for most jobs. The contoured shell is a styling choice rather than a security one — it is simply the better-looking lock, and the one to fit on a front gate, a shopfront shutter, a display cabinet or anywhere the padlock is seen rather than hidden round the back of a shed.

Underneath the styling it is a proper outdoor lock. A rubber waterproof ring seals the keyway, and behind that seal sits an all-copper lock core running five brass pins — the same pin count as a standard house door cylinder, not the three- or four-pin wafer mechanism you get in a cheap hardware-shop padlock. The pins give it something to resist a rake with; the seal is why it keeps turning after a wet winter instead of seizing up.

The Ø8mm A3 steel shackle gives 27mm of clearance, which takes most gate hasps, a garage latch or a light chain, and the moulded case keeps the lock from marking a powder-coated gate. Three steel keys are supplied. For a yard gate, compound, container or trailer, the 75mm steps up to a Ø11.8mm shackle and a 6-pin cylinder.

• 50mm steel body in a sculpted waterproof wave-shell case
• Styled to be seen — for gates, shutters and doors on display
• Rubber waterproof ring seals the keyway against rain and dust
• Solid brass 5-pin cylinder — house-door pin count, all-copper lock core
• A3 steel shackle, Ø8mm with 27mm clearance
• 3 steel keys supplied
• Suits gates, sheds, garages, storage, toolboxes and cabinets

Security features

Specifications

• Body material: Steel with moulded waterproof wave-shell case
• Cylinder: Solid brass, 5-pin — all-copper lock core
• Shackle: A3 steel, black finish
• Locking system: Bolt locking — steel spring, steel pins
• Weather sealing: Rubber waterproof ring
• Keys supplied: 3 x steel keys
• Body size: 45 x 54 x 27 mm (W x H x D)
• Shackle: 8 mm diameter, 27 mm clearance
• Weight: approx. 320 g
• Packaging: Double blister
• Country of origin: China
